APPLICATION：

The machine is used for the sewing processing of nonwoven fabric, to increase its fastness and toughness, which is widely used in the field of health care, clothing lining.

CHARACTERISTIC：

Feed, stretch, warp, take-up are all controlled by servo motor, good synchronization.

We can choose 1 or 2 bars. With 2 bars, the fabric has a significantly improved in stability, strength, anti-loose and sliding resistance.

MAIN TECHNICAL SPECS：

Needle type	Compound Needle
Gauges	E3.5, E5, E7, E9
Working width	2900 mm
Guide bar number	1, 2
Main drive	Eccentric linkage
Speed	1800 rpm
Pattern drive	Pattern disk
Yarn let-off device	EBA electronic yarn let-off
Feed device	Electronic feed
Fabric take-up	Electronic take-up device
Batching device	Electronic batching device
Main motor power	5.5 kw

•
•
•
